研华PCE-5B05V 5-slot Butterfly BP for 2U chassis

  • 5-slot Butterfly BP for 2U chassis
  • Segment: 1
  • One CPU card slot
  • PCIe slot: One x16
  • PCI-X slot: Two 64/100; one 64/133
  • PCI slot: N/A
  • Compatible with IPC chassis: ACP-2000EBP
  • Complying with System Host Board (SHB Express; also called PICMG 1.3) standards, these SHBs feature the latest PCI Express technology, offering scalable I/O bandwidth of more than 10 GB/s. They maintain compatibility with PCIe, PCI-X, PCI and ISA, and allow customers to leverage commercial I/O cards. Advantech's SHBs empower system designers to create a new generation of servers, workstations and industrial platforms.
